GYSMI E200 FV
Earn 400 points with this purchase
£480.00 £534.00Price range: £400.00£480.00 through £445.00£534.00 Exc VATInc VAT
Complete your machine in three quick steps
Choose your free plug and SGL-picked safety package. Unlock up to 20% off selected categories.
Machine guide
- Processes
- DC/Lift TIG / MMA/ARC
- Power supply
- 110/230V single-phase (dual voltage)
- Duty cycle
- MMA: 200A @ 20%; TIG: 200A @ 30%
- Suitable metals
- mild/carbon steel, stainless steel, copper/brass, cast iron or dissimilar steels with the correct electrode
- Single-pass
- TIG: about 0.5–8 mm; MMA: about 2–10 mm
- Multi-pass
- TIG: up to about 16 mm; MMA: up to about 20 mm
Practical selection guide, not a guaranteed manufacturer limit. Capacity changes with process, metal, joint design, preparation, consumables, position, duty cycle and operator technique; figures assume maximum rated output on the appropriate supply.
GYSMI E200 FV
The GYSMI E200 FV is a 200A dc/lift tig / mma/arc machine for workshop, fabrication, maintenance or site work. The summary below makes its processes, electrical supply and practical material capacity easy to compare.
Machine capability at a glance
| Processes | DC/Lift TIG / MMA/ARC |
|---|---|
| Power supply | 110/230V single-phase (dual voltage) |
| Suitable metals | mild/carbon steel, stainless steel, copper/brass, cast iron or dissimilar steels with the correct electrode |
| Typical single-pass guide | TIG: about 0.5–8 mm; MMA: about 2–10 mm |
| Typical multi-pass guide | TIG: up to about 16 mm; MMA: up to about 20 mm |
Practical selection guide, not a guaranteed manufacturer limit. Capacity changes with process, metal, joint design, preparation, consumables, position, duty cycle and operator technique; figures assume maximum rated output on the appropriate supply.
Full product details
The GYSMI E200 FV is a cutting-edge inverter technology, microprocessor-controlled welding unit designed for versatile and intensive use. Featuring a user-friendly keyboard and a digital display, this multi-purpose equipment operates efficiently on a 16A-230V power supply, ensuring high performance even under demanding conditions. Key Features:
- Versatile Welding Capabilities:
- Electrode Compatibility: Welds a variety of electrodes (Ø1.6 to 5 mm) including steel, stainless steel, cast iron, rutile, and basic.
- High Duty Cycle: Designed for intensive use with a stable arc and constant intensity.
- Advanced Welding Technology:
- Anti-Sticking: Prevents electrodes from sticking, enhancing ease of use.
- Adjustable Hot Start: Facilitates easier arc initiation on different metals:
- Low Hot Start: Ideal for thin metal sheets.
- High Hot Start: Suitable for metals that are difficult to weld, such as dirty or oxidized sheets.
- Arc Force: Enhances penetration and prevents sticking, ensuring high-quality welds.
- TIG Welding Capabilities:
- TIG Lift: Initiates the arc by touching the metal with the tungsten electrode, avoiding tungsten inclusions and radio electrical disturbances.
- Automatic Arc Release: Allows the operator to finish welding without creating craters. This feature is adjustable and activated by a torch movement.
- Included Accessories:
- Earth Clamp: 1.6m cable with a 16mm² diameter.
- Electrode Holder: 2m cable with a 16mm² diameter.
- Optional TIG Torch: Available as an additional accessory (ref 044425):
- Length: 4m
- Connector: 10/25 mm
Package Contents: The GYSMI E200 FV is delivered in a durable case complete with essential accessories, making it ready for immediate use upon delivery.
| PACKAGE ONLY OR WITH TIG TORCH | Machine, MMA Leads and Case Package, With TIG Torch (+£45) |
|---|
